| Pickup Device |
Sony 1/3 inch1.3MP CMOS Sensor(IMX225LQR) |
| Total Pixels |
1312 (H) × 993 (V) approx. 1.30 M pixels |
| Active Pixels |
1305(H) ×977 (V) approx. 1.27 M pixe |
| Scanning System |
4:3 Progressive Scan |
| Sync. System |
Internal |
| Min. Illumination |
0.06Lux(F2.5 - 30IRE), 0.002Lux(DSS on) |
| Video Out |
720P @25/30P AHD 1.0 |
| SN ratio |
More than 42dB (AGC Off) |
| SUTTER SPEED |
Auto / FLK / 1/60(1/50)Sec ~ 1/50000Sec,X2,X4,X6,X 8,X10,X15,X20,X25,X30 |
| White Balance |
AWB, ATW, AWC -> SET, Manual, Indoor, Outdoor |
| Function |
OSD,AE,Exposure,BLC,HSBLC,DN EXT,Audio option and so on. |
| Operating Humidity |
- 20℃ - +60℃ (10% - 95% RH) |
| Lens |
STD Lens : 92' or 120' (With 645n OLPF) |
| Sensor MTBF |
80,000 Hour |
| Power Suply Range |
DC 12V 10% |
| Power Source |
MAX. DC12V 90mA |
| Dimensions |
41(H) x41(V) x43(W)mm |
| Net Weight |
50g |
